ASA-3000S ESD electric screwdriver with AM-45 controller Maximize

ASA-3000S ESD + AM-45

ASA-3000S ESD electric screwdriver with AM-45 controller

Send inquiry
×

ASA-3000S ESD electric screwdriver with AM-45 controller

Torque: 0.05 - 0.5 Nm

No load speed: 700 - 1000 rpm

Bit type: 1/4 HEX

Type: ESD type

Start type: lever start

Shut off: automatic

Direction: clockwise / counter-clockwise

Motor: with carbon brush

Accuracy: +- 3%

Weight: 380 g

Length: 208 mm

Grip diamater: 32 mm

Machine screw size: 1 - 2.6 mm

Tapping screw size: 1 - 2.3 mm

Product informations AM-45 control unit: input voltage 100 - 240 VAC 50 / 60 Hz,  output voltage 20 - 30 VDC, connection 5 pin, power 75 W, weight 450 g, dimension 172 x 81 x 61 mm

AM-45 electronic control unit setting: workpiece counter 1-60,000 pieces, 1-99 piece / work piece, screw time 0.01-9.99 seconds, parameter sets 10 pieces - sequence individually or sequentially adjustable from 0.01-9.99 seconds, Output signal / ready for operation - Torque reached - Workpiece complete OK - Single screw operation OK - Error screwdriving, input signal / release screwdriver

Scope of supply: ASA-3000S ESD screwdriver, AM-45 control unit, screwdriver cable

More details

Product details
Torque 0.05 - 0.5 Nm
No load speed 700 - 1000 rpm
Bit type 1/4 HEX
Type ESD type
Start type lever start
Shut off automatic
Direction clockwise / counter-clockwise
Motor with carbon brush
Accuracy +- 3%
Weight 380 g
Length 208 mm
Grip diamater 32 mm
Machine screw size 1 - 2.6 mm
Tapping screw size 1 - 2.3 mm
Product informations AM-45 control unit input voltage 100 - 240 VAC 50 / 60 Hz,  output voltage 20 - 30 VDC, connection 5 pin, power 75 W, weight 450 g, dimension 172 x 81 x 61 mm
AM-45 electronic control unit setting workpiece counter 1-60,000 pieces, 1-99 piece / work piece, screw time 0.01-9.99 seconds, parameter sets 10 pieces - sequence individually or sequentially adjustable from 0.01-9.99 seconds, Output signal / ready for operation - Torque reached - Workpiece complete OK - Single screw operation OK - Error screwdriving, input signal / release screwdriver
Scope of supply ASA-3000S ESD screwdriver, AM-45 control unit, screwdriver cable
